TP-Link Archer AXE5400 Tri-Band Gigabit Wi-Fi 6E Router, Wi-Fi 6E (802.11ax), Tri-band (2.4 GHz / 5 GHz / 6 GHz), Ethernet LAN, Black, Tabletop router
Antenna
| Antenna design | External |
|---|---|
| Antennas quantity | 6 |
| Detachable antenna(s) | Yes |
| Transmit power | FCC: ≤29dBm (2.4 GHz), ≤28dBm (5 GHz), ≤22dBm (6 GHz) CE: ≤17dBm (2.4 GHz), ≤27dBm (5 GHz), ≤20dBm (6 GHz) |
Design
| On/off switch | Yes |
|---|---|
| Reset button | Yes |
| LED indicators | Power, WAN, WLAN |
| Product type | Tabletop router |
Ergonomics
| Wall mountable | Yes |
|---|
Features
| Product colour | Black |
|---|---|
| Power source type | DC |
| Security algorithms | WPA, WPA-Enterprise, WPA2, WPA3 |
| Built-in processor | Yes |
| Processor cores | 4 |
| Firmware upgradeable | Yes |
Logistics data
| Harmonized System (HS) code | 85176990 |
|---|---|
| Customs product code (TARIC) | 8517620000 |
Management features
| Quality of Service (QoS) support | Yes |
|---|---|
| WPS push button | Yes |
| Web-based management | Yes |
| Wake-on-LAN ready | Yes |
| Wireless statistics | Yes |
Network
| Ethernet LAN | Yes |
|---|---|
| Top Wi-Fi standard | Wi-Fi 6E (802.11ax) |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax) |
| Ethernet LAN interface type | Gigabit Ethernet |
| Ethernet LAN data rates | 2500 Mbit/s |
| Cabling technology | 10/100/1000Base-T(X) |
| Port forwarding | Yes |
| Port triggering | Yes |
| Dynamic DNS (DDNS) | Yes |
| Number of guest networks (2.4 GHz) | 1 |
| Number of guest networks (5 GHz) | 1 |
| Built-in FTP server | Yes |
| VPN server | OpenVPN Server |
| Media server | Yes |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11n |
| Support Samba (storage) | Yes |
| Static route | No |
| VPN Passthrough | Yes |
| VPN support | OpenVPN Server PPTP VPN Server L2TP VPN Server |
Operational conditions
| Operating temperature (T-T) | 0 - 40 °C |
|---|---|
| Operating relative humidity (H-H) | 10 - 90% |
Other features
| Weight | 710 g |
|---|---|
| Country of origin | China |
| AC adapter included | Yes |
Packaging content
| Cables included | LAN (RJ-45) |
|---|---|
| Number of products included | 1 pc(s) |
| Quick installation guide | Yes |
Packaging data
| Package width | 118 mm |
|---|---|
| Package depth | 262.5 mm |
| Package height | 320 mm |
| Package weight | 1.27 kg |
Ports & interfaces
| DC-in jack | Yes |
|---|---|
| USB port | Yes |
Power
| Output voltage | 12 V |
|---|---|
| Output current | 2.5 A |
Processor
| Processor frequency | 1700 MHz |
|---|
Protocols
| DHCP client | Yes |
|---|---|
| DHCP server | Yes |
| Universal Plug and Play (UPnP) | Yes |
| Supported network protocols | IPv4, IPv6 |
Rear panel I/O ports
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
|---|---|
| Ethernet LAN (RJ-45) ports | 4 |
Security
| Firewall | Yes |
|---|---|
| DoS attack prevention | Yes |
| DDoS protection | Yes |
| DMZ support | Yes |
| Network address translation (NAT) | Yes |
| Access Control List (ACL) | Yes |
| MAC address filtering | Yes |
| IP address filtering | Yes |
| Firewall security | SPI Firewall |
| Guest access | Yes |
| URL filtering | Yes |
Sustainability
| Compliance certificates | Federal Communications Commission (FCC), RoHS |
|---|---|
| Sustainability compliance | Yes |
WAN connection
| Ethernet WAN | Yes |
|---|---|
| DSL WAN | No |
| SIM card slot | No |
| 3G/4G USB modem compatibility | No |
| WAN connection type | RJ-45 |
Weight & dimensions
| Width | 147.2 mm |
|---|---|
| Depth | 49.2 mm |
| Height | 272.5 mm |
Wireless LAN features
| Wi-Fi band | Tri-band (2.4 GHz / 5 GHz / 6 GHz) |
|---|---|
| WLAN data transfer rate (max) | 5400 Mbit/s |
| WLAN data transfer rate (first band) | 574 Mbit/s |
| WLAN data transfer rate (second band) | 2402 Mbit/s |
| WLAN data transfer rate (third band) | 2402 Mbit/s |
General
| Brand | TP-Link |
|---|---|
| Manufacturer part number | ARCHER AXE75 |
Ungrouped
| Gtin | 4897098687482 |
|---|
Reaching New
Peaks of Performance
WiFi 6E: A Freer and Faster Future
WiFi 6E introduces the brand new 6 GHz band without any overlap or interference from other bands and older devices. This means a congestion-free frequency that offers more bandwidth, faster speed, and lower latency.
Maximize All Your Device Speeds
Archer AXE75 provides WiFi speeds up to 5400 Mbps, enabling your devices to run at full speed. Enjoy fluent 4K/8K streaming, immersive AR/VR gaming, and blazing-fast downloads.
More RAM, Better Processing
With an advanced chipset and high memory, experience fast connections with minimal latency even under heavy loads. Every click and tap on your laptop or phone responds quicker.
Connect More Stay Fast
The number of IoT devices today creates greater demands on home WiFi. Archer AXE75 future-proofs your home network with a higher capacity of up to 200+ devices. OFDMA and other advanced tech cut down the clutter throughout your frequency bands, eliminating latency and jitter.
WiFi Coverage Throughout Your Home
6× high-performance antennas boost WiFi signals throughout your home. Beamforming technology detects devices and concentrates signals towards them, especially to previously hard-to-reach areas.
USB 3.0
Easily share files between connected devices with an external drive. Or create your own personal cloud storage for simple, secure access from anywhere.
TP-Link OneMesh
Flexibly Create Whole Home WiFi with Archer AXE75
OneMesh is a simple way to form a mesh network with a single WiFi name for seamless whole home coverage. Just connect a OneMesh range extender to a OneMesh router. No more searching for a stable connection.
TP-Link HomeShield
Advanced Security for Your Everyday Devices
With TP-Link HomeShield, enjoy advanced secuirty features delivering a safe environment that protects your family and network's data and privacy.
WPA3: Stronger Security for Your Network
The latest WiFi security protocol, WPA3, brings new capabilities to improve cybersecurity in personal networks. More secure encryption in WiFi password safety and enhanced protection against brute-force attacks combine to safeguard your home network.
Easy Setup and Use
Whether you prefer the intuitive Tether app or TP-Link’s powerful web interface, you can set up your Archer AXE75 in minutes. The Tether app allows you to manage network settings from any Android or iOS device.
Protect Your Children
Block inappropriate content for your children, and customize a time range for better online habits.
New Connection Notification
You will be notified by your phone when new devices connect. Kick off any suspicious connections and block them. It’s as simple as that.
Easy Firmware Upgrade
Tired of upgrading firmware? OTA updates enable easy firmware upgrades with a click in the management panel. To keep your security and functions always up-to-date, just turn on the auto schedule.
